PU Foam Sponge, Cell Pad

To use
- Protection of major parts from external shock; compensation of height difference through compression/recovery; and reduction of vibration/noise
Advantage
- Layer suited for various purposes(1 layer to 3 layers); fire retardant performance(UL94 HBF)
- Adjustment of shock absorption rate through diversification of density(density: 0.18 ~ 0.7g/m²)
- Adjustment in a way that suits the properties of adherent (compression recovery rate: slow/normal/fast)

Product Structure

Please slide the table to check.

Classification	Foam (1 Layer)	PET integrated type (2 Layer)	Adhesion integrated way (3 Layer)	Skin integrated type (2 Layer)	Light-shielding integrated type (3 Layer)
Structure
	PU Foam (Cell Pad)	PU Foam	PU Foam	PU Foam	Black PET
		PU Foam	PET	PU Foam	PU Foam
		PET	Adhesion(PSA)	Skin	Skin
Thickness (mm)	0.1 ~ 3.0	0.15 ~ 3.0	0.1 ~ 4.5	0.1 ~ 3.0	0.2 ~ 3.0
Application Fields	Mass production of secondary batteries is in progress	Mass production of smartphones is in progress	Mass production of foldable phones is in progress	Mass production of monitors/TVs is in progress	Mass production of monitors/TVs is in progress

Fire retardant/non-fire retardant double-sided tape for secondary cells

To use
- Tape with excellent heat resistance, used for assembling and fixing the batteries
Advantage
- Obtained the fire retardancy rating UL510A (certification organization: UL)
- Operation of tape manufacturing line advantageous for foreign matter control
- Cleanliness: Operation of tape production line 1,000 class and adhesion coating zone 100 class
- Lineup by thickness: 0.03 / 0.1 / 0.15 mm

Product Structure

Please slide the table to check.

Thickness	0.03mm	0.01mm	0.015mm
Structure	Release Film Fire retardant adhesion 9um PET film 12um flame retardant 9um Release Film	Release Film Fire retardant adhesion 27um PET film 25um flame retardant 38um Release Film	Release Film Fire retardant adhesion 37um PET film 75um flame retardant 38um Release Film
Adhesion (at room temperature, based on Sus)	1,600 gf/in	2,100 gf/in	2,200 gf/in
Flame retardant rating	UL510A	UL510A	HBF
